Özellik
Digital twin 16+2+2 phases VRM solution, Dual Channel DDR5: 4xDIMMs with AMD EXPO Memory Module Support, WIFI EZ-Plug: Quick and easy design for Wi-Fi antenna installation, EZ-Latch Plus: PCIe and M.2 slots with Quick Release & Screwless Design, EZ-Latch Click: M.2 heatsinks with screwless design, Sensor Panel Link: Onboard video port for hassle-free in-chassis panel setup, Friendly UI: Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW. New Power Monitor in HWinfo for real-time monitoring on CPU power phases, Ultra-Fast Storage: 4xM.2 slots, including 3x PCIe 5.0 x4, Efficient Thermal: VRM Thermal Armor Advanced & M.2 Thermal Guard L, Fast Networking: 2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna, Extended Connectivity: Dual USB4 Type-C with DP-Alt, HDMI, Reliable Audio: Realtek ALC1220 HD Audio & Audiophile Grade Capacitors, Ultra Durable PCIe Armor: The metal back plate of PCIe x16 slot for enhanced durability. PCIe UD Slot X: PCIe 5.0 x16 slot with 10X strength for graphics card
Diğerleri
Internal I/O Connectors: 1 x 24-pin ATX main power connector, 2 x 8-pin ATX 12V power connectors, 1 x CPU fan header, 1 x CPU fan/water cooling pump header, 4 x system fan headers, 2 x system fan/water cooling pump headers, 3 x addressable RGB Gen2 LED strip headers, 1 x RGB LED strip header, 4 x SATA 6Gb/s connectors, 4 x M.2 Socket 3 connectors, 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C header, with USB 3.2 Gen 2x2 support, 2 x USB 3.2 Gen 1 headers, 2 x USB 2.0/1.1 headers, 1 x noise detection header, 1 x HDMI port (Note), 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI2.0/GC-TPM2.0 SPI V2 module only), 1 x power button, 1 x reset button, 2 x temperature sensor headers, 1 x reset jumper, 1 x Clear CMOS jumper, I/O Controller: iTE I/O Controller Chip, H/W Monitoring, Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control, Unique Features: Support for GIGABYTE Control Center (GCC), Support for Q-Flash, Support for Q-Flash Plus, Support for Smart Backup
