2 x M.2 (1 x M.2, type 2280 PCIe 4.0 x4/x2 SSD support) (M2A_CPU), (1 x M.2, M key, type 2280 PCIe 4.0 x4/x2 SSD support) (M2P_SB)
M.2/SSD Slot Gen
Up to Gen 4
Graphics
Grafikler
Integrated
Graphics Chipset
Intel HD Graphics support
Multi-GPU Support
No
PCI Express Slot
1 x PCI Express x16 slot, 2 x PCI Express x1 slots
Audio & Video
Ses Çipseti
Realtek Audio CODEC, High Definition Audio
Audio Channel
7.1
Network & Connectivity
LAN Çipseti
Realtek GbE LAN chip
LAN Speed (Mbps)
10/ 100/ 1000Mbps
WiFi
No
Bluetooth
No
Ports
USB Bağlantı Noktası
2 x USB 2.0/1.1 ports, 3 x USB 3.2 Gen 1 ports
VGA Port
1
DVI Port
No
HDMI Port
1
DisplayPort (DP)
1
SATA Port
4
Thunderbolt
No
TPM Port
1
Technical Info
Arka Bağlantı Tasarımı
HAYIR
Cable Management
Front
Heatsink
No
FireWire
No
CrossFire Support
No
Sli Support
No
Raid Support
0/ 1/ 5/ 10
RGB Support
RGB
RGB Connector
1 x RGB LED strip header
Approx. Power Consumption
60W
Form Factor
Micro-ATX
Bios Information
BIOS Türü
1 x 128 Mbit flash
BIOS Model
AMI UEFI BIOS
BIOS Version
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Compatibility
Desteklenen İşletim Sistemi
Windows 10, Windows 11
Compatible Products
LGA1700 socket: Support for the 14th, 13th, and 12th Generation Intel Core, Pentium Gold and Celeron Processors
Warranty
Garanti Detayları
3 yıl
Additional Info
Özellik
Supports Intel Core 14th/ 13th /12th processors, Unparalleled Performance: Hybrid 4+1+1 Phases Digital VRM Solution, Dual Channel DDR4: 4xDIMMs XMP Memory Module Support, Next Generation Storage: 2xPCIe 4.0 x4 M.2 Connectors, Fast Networks: GbE LAN, Extended Connectivity: DP, HDMI, D-Sub, Smart Fan 6: Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP, Q-Flash Plus: Update BIOS Without Installing the CPU, Memory and Graphics Card
Others
Internal I/O Connectors: 1 x 24-pin ATX main power connector, 1 x 8-pin ATX 12V power connector, 1 x CPU fan header, 3 x system fan headers, 1 x addressable LED strip header, 1 x RGB LED strip header, 2 x M.2 Socket 3 connectors, 4 x SATA 6Gb/s connectors, 1 x front panel header, 1 x front panel audio header, 1 x USB Type-C header, with USB 3.2 Gen 1 support, 1 x USB 3.2 Gen 1 header, 2 x USB 2.0/1.1 headers, 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 / GC-TPM2.0 SPI V2 module only), 1 x serial port header, 1 x parallel port header, 1 x S/PDIF Out header, 1 x Q-Flash Plus button, 1 x reset jumper, 1 x Clear CMOS jumper, I/O Controller: iTE I/O Controller Chip, H/W Monitoring: Voltage detection, Temperature detection, Fan speed detection, Water cooling flow rate detection, Fan fail warning, Fan speed control, Unique Features: Support for GIGABYTE Control Center (GCC), Support for Q-Flash, Support for Q-Flash Plus
Country Of Origin
Taiwan
Made in/ Assemble
China
N.B. Görsel, ürünün gerçek düzeni, rengi, boyutu ve ölçülerinden farklılık gösterebilir. Görsel uyumsuzluğu nedeniyle herhangi bir talep kabul edilmeyecektir. Bu web sitesinde kullanılan ürün verileri yalnızca üretici tarafından sağlanan bilgilere dayanmaktadır; orijinalliği ve doğruluğu yalnızca üreticinin sorumluluğundadır.
Detaylar
SORU & CEVAP
Müşteri Soruları
Q:
Core i3/i5/i7/i9 support
Asked By JEWEL SARKAR
A:
Dear Customer, This motherboard supports all Core i3/i5/i7/i9 processors, including 14th generation, 13th generation , and 12th generation processors. Thanks.
My previous motherboard was outdated and could barely upgrade my cpu, so this motherboard is a great upgrade piece to get more expensive and much more powerful cpu's. Definitely worth it's price!
By Dr. Sayem Uddin
. December, 2024
robust performance, reliable connectivity, and excellent value for building a solid and future-proof PC.
By Rajib
. December, 2024
I hope it will be the best product
By Arjun Sengupta
. November, 2024
Ultimate
By Adnan
. November, 2024
Outstanding performance
By Golam Rasul
. November, 2024
The quality of the product is very good according to the price and Specifications of product .
By Md. Saleh
. November, 2024
this motherboard delivers impressive performance and solid expandability without compromising on quality.
By Opu Mirza
. November, 2024
Good performance
By Mr. Fazle Rabby
. November, 2024
Outstanding service
By Akram
. November, 2024
Great Motherboard
By Mr. Jewel
. November, 2024
