HDMI (HDCP 2.3), HDMI Out, HDBaseT, Variable Audio Out: Mini Stereo, USB Connector Type-A , USB Connector Type-B Serial: RS-232c, Wired LAN RJ45
HDMI
3
USB
USB Type-A x 1, USB Type-B x 1
Audio
Mini Stereo x 1
Memory Card Slot
No
LAN
1 x RJ45
Wireless LAN / Wi-Fi
Yes
Additional I/O Ports & Connectivity
HDMI (HDCP 2.3) x 2, HDMI Out x 1, HDBaseT x 1, Variable Audio Out: Mini Stereo x 1, USB Connector Type-A x 1, USB Connector Type-B x 1, Serial: RS-232c x 1, Wired LAN RJ45 x 1.
Sound
Speaker
10 W (mono)
Sound Mode
Mono
Integrated Speaker
Yes
Watts Per Channel
10Watt
Physical Description
Remote Control Included
Yes
Color
White
Dimensions
440 x 340 x 138mm
Weight (Kg)
8.66 kg
Package Contents
PowerLite L790U laser projector, power cable, projector remote control with batteries, Quick Reference card, cable cover
Software
Operating System
Unmentioned
Power
Power Source
100V - 240 V +/- 10%, 50/60 Hz AC
Approx. Power Consumption
415 W (Normal Mode), 305 W (Quiet and extended), 2.4 W (Standby comm on), 0.3 W (Standby comm off)
Warranty
Warranty Details
2 year (1st Year Parts, 2nd Year Service) (Lamp 12 Month/1000 Hours Which One Comes First)
Additional Info
Others
Projection System: RGB liquid crystal shutter projection system Projection Method: Front/rear/ceiling mount, LCD Size: 0.67 inch (C2Fine), Driving Method: Poly-Silicon TFT Active Matrix, Pixel Number: 2,304,000 dots, Pixel Arrangement: Cross stripe, Brightness Uniformity (Typical): 88%, Focal Length: 20.0 mm - 31.8 mm, Frequency Type (Modulations): 802.11 b/g/n/ac/ax (2.4 GHz), Supported Security Type Quick Mode: Open, WPA2/ WPA3-PSK, WPA2/ WPA3-EAP; Advanced Mode: WPA/WPA2-PSK, WPA/ WPA2-EAP, Operating Temperature 0 Degree C to 45 Degree C, Auto Power On Signal Detection on HDMI/Plug-In Detection, Sleep Mode: Yes (with timer); HDMI CEC Control: Yes; Fan Noise: 34 dB (Normal Mode), max. 26 dB (ECO Mode); Security Security cable hole, Kensington lock provision Miracast: Yes, Epson iProjection: Yes (V4), Apple AirPlay: Yes, Split Screen: Yes (up to 2 screens), Content Playback: Yes, Quick Corner: Yes, Corner Wall: Yes, Curved Surface: Yes, Edge Blending: Yes, Screen Sharing: Yes, Pixel Clock 25.1 MHz - 594 MHz, Horizontal 26 kHz - 135 kHz, Vertical 23.98/ 24/ 25/ 29.97/ 30/ 50/ 59.94/ 60 Hz, Features power, source search selection, A/V mute, number input, menu, esc, select, freeze, ID, customize, E-zoom, mute, volume, playback control, and pointer functions. Operating Angle Rear: Right/Left: -55 to +55 degrees; Upper/Lower: +75 to +15 degrees; Front: Right/Left: -30 to +30 degrees; Upper/Lower: 0 to +60 degrees, Operating Distance 26 ft (8 m), Network Control PJLink, Crestron Integrated Partner, Crestron Connected V2 with XiO Cloud, Extron IP Link, Extron XTP, AMX Control
Specialty
Ultra-bright, true-to-life images Full HD WUXGA resolution, Large, versatile display options Simplified installation Low maintenance, Wireless networking and content sharing Works with Apple AirPlay. Built-in NFC, Optional attachable PixAlign camera Over-the-air updates Enhanced connectivity
Country Of Origin
Japan
Made in/ Assemble
China/ Indonesia/ Philippine (or Country may vary by Shipment)
